CATEGORY WASHER
MODEL SCK060
SIZE(mm) 865(W)x1,135(D)x1,295(H)
CAPACITY 30kg
NET WEIGHT 308kg






SPEC

Model SCK040 SCK060 SCK080 SCK100
Wash Capacity 20kg 30kg 40kg 50kg
Size(WxDxH) 778x1,073x1,227mm 865x1,135x1,295mm 1,054x1,196x1,481mm 1,054x1,298x1,481mm
Cylinder Volume 178L 255L 365L 430L
Motor Power
/Inverter Capacity
1.5kW/2HP 2.25kW/3HP 3.75kW/5HP 3.75kW/5HP
W/D RPM 33/733 31/686 28/626 28/568
G-force 200 200 200 165
Electric Specification 220V / 1 / 60Hz 220V / 1 / 60Hz 220V / 1 / 60Hz 220V / 1 / 60Hz
Water Inlet/Drain 20/75mm 20/75mm 20/75mm 20/75mm
Net Weight 245kg 308kg 567kg 581kg

* Design and specifications subject for modification without prior notice.

  • POWER of 200 G-force

    Powerful rotational speed of 200 G-force can remove up to 1/3 gallon of water per spin cycle, reducing electricity usage by up to 15%.
  • Control Unit & Inverter

    The control device is composed of a simple, intuitive program, with an inverter-type motor control to reduce power consumption.
  • Door Handle and Locking Indicator

    The door handle uses AI for ease of use and to reduce the risk of alignment problems and door-lock errors.
  • Large Door Opening

    The stainless steel door is completely sealed, with a large door opening for easy loading and unloading.
